Drawer (y), Part list, Assembly instructions 8/8 – Home Styles 5018-95 User Manual

Page 9: Step 2 step 3 step 4, Step 1

Figure 2

MAKE SURE ROLLER
IS ON THE BACK

Figure 3

Figure 4

Insert

wood screws (6X)

into the pre-drilled holes in Y5
and tighten. (see Figure 3)

short

Slide Y5 into the grooves in Y3
and Y4. Be sure to push Y5 all
the way forward so it meets Y1.
(see Figure 2)

STEP 2

STEP 3

STEP 4

Tighten all screws used in drawer assembly.

Assemble Pull Handle with
machine screws. (see Figure 4)

Assembly Instructions 8/8

Part List

Y1.
Front Part
2 pcs.

Y5.
Base Part
2 pcs.

Y2.
Back Part
2 pcs.

Y3.
Side Part
2 pcs.

Y4.
Side Part
2 pcs.

Drawer (Y)

Attach Y1 to Y3 and Y4, using
a

and

wood screws

tighten halfway.

Attach Y2 to Y3 and Y4 using

wood screws

tighten halfway. (see Figure 1)

Phillips screwdriver

(4X)

long

Figure 1

STEP 1
