Home Styles 9001-0111 - Manual

IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damage occurring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List
Home Styles Consumer Assistance: www.homestyles-furniture.com,
[email protected], 888-680-7460, 877-831-0319
Hardware List
88 9001 001C
Cuisine Cart
(Please refer to the last page of these
instruction for drawer assembly steps)
Tools required for assembly : Phillips screwdriver
Hex Wrench
1 Pc.
Head Cap Bolt(Middle)
for Top
4 Pcs. (+1 extra)
Head Cap Bolt(long)
12 Pcs. (+1 extra)
Head Cap Bolt
for Side Tower Bar
2 Pcs. (+1 extra)
Wood Plug
8 Pcs. (+1 extra) Adjustable Pin
4 Pcs. (+1 extra)
Wood Screw
for Caster
16 Pcs. (+1 extra)
Small Hex Wrench
1 Pc.
Caster
two lock
two non-lock
4 Pcs.
C.
Base
1 Pc.
A.
Side Panel
1 Pc.
H.
Side Rack
1 Pc.
I.
Side Rack
1 Pc.
K.
Base Rack
1 Pc.
P.
Drawer
1 Pc.
N.
Door
1 Pc. O.
Door
1 Pc.
M.
Shelf
1 Pc.
L.
Side Tower Bar
1 Pc.
B.
Side Panel
1 Pc.
F.
Back Stretcher
1 Pc.
G.
Front Rail
1 Pc.
D.
Back Upright
1 Pc. E.
Back Panel
2 Pcs.
J.
Brush Chrome Pipes
3 Pcs.
Knob
2 Pcs.
Machine Screw
for Knob
2 Pcs.
