Home Styles 5180-64 User Manual
Arts & crafts pantry, Part list hardware list
Part List
Hardware List
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the wood parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Cam Lock Screw
28 pcs.(+1 extra)
88 5180 64
Arts & Crafts Pantry
Flat Washer
4 pcs. (+1 extra)
Hex Wrench
1 pc.
Small
Hex Wrench
1 pc.
Tools required for assembly :
Tools recommended for assembly :
Phillips screwdriver
Level
Home Styles Consumer Assistance: www.homestyles-furniture.com,
[email protected], 888-680-7460, 877-831-0319
Knob
4 pcs.
Machine Screw
8 pcs.
Adjustable Pin
16 pcs. (+1 extra)
Wood Screw
for Back Panel
16 pcs. (+1 extra)
Cam Lock
28 pcs.(+1 extra)
S.
Door
1 pc.
D.
Bottom
1 pc.
N.
Top
1 pc.
Q.
Side Panel
1 pc.
H.
Door
1 pc.
U.
Back Post
1 pc.
T.
Back Panel
2 pcs.
O.
Front Rail
1 pc.
L.
Leg Frame
1 pc.
M.
Back Rail
4 pcs.
P.
Side Panel
1 pc.
K.
Leg Frame
1 pc.
C.
Shelf
4 pcs.
A.
Top
1 pc.
B.
Front Rail
1 pc.
E.
Side Panel
1 pc.
F.
Side Panel
1 pc.
G.
Door
1 pc.
R.
Door
1 pc.
I.
Back Panel
2 pcs.
J.
Back Post
1 pc.
Spring Washer
4 pcs. (+1 extra)
Head Cap Bolt
4 pcs. (+1 extra)
