IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Tools required for assembly :
Phillips screwdriver
88 5033 942
Nantucket Kitchen Island
C.
Side Panel
1 pc. B.
Side Panel
1 pc.
D.
Side Panel
1 pc.
E.
Side Panel
1 pc.
F.
Side Panel
1 pc.
G.
Side Panel
1 pc.
I.
Back Stretcher
2 pcs.
K.
Back Panel
2 pcs.
L.
Shelf
4 pcs.
M.
Shelf
1 pc.
P.
Base
1 pc. U.
Door
1 pc. T.
Door
1 pc.
For assembly see instructions in carton 88 5033 941
Hex Wrench
1 pc.
Head Cap Bolt
24 pcs. (+1 extra)
Cam Lock
16 pcs.(+1 extra)
Cam Lock Screw
16 pcs.(+1 extra) Machine Screw
6 pcs.
Adjustable Pin
20 pcs. (+1 extra)
Small
Hex Wrench
1 pc.
Pull Handle
2 pcs.
Wood Screw (short)
for Drawer Base Part
6 pcs. (+1 extra) Wood Screw (long)
for Drawer Side Part
8 pcs. (+1 extra)
Pull Handle
2 pcs.
Hardware List
Tools recommended for assembly :Level
S.
Plinth
2 pcs.
H2.
Front Rail
1 pc.
Wood Screw
for Hinge
27 pcs. (+2 extra)
