Home Styles 5033-94 - Manual

Part List
88 5033 941
Nantucket Kitchen Island
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Tools required for assembly :
Phillips screwdriver
Home Styles Consumer Assistance Line 888-680-7460 and 877-831-0319
[email protected]
A1.
Top
1 pc.
J.
Stretcher
1 pc.
H1.
Front Rail
1 pc.
R.
Leg Support
1 pc.
Q.
Plinth
2 pcs.
O.
Back Support
1 pc.
N.
Back Support
1 pc.
V.
Drawer
1 pc.
Also need the following from carton 88 5033 942 :
Hardware List in carton 88 5033 942
Hex Wrench
Small Hex Wrench
Cam Lock Screw
Cam Lock
Head Cap Bolt
Adjustable Pin
Pull Handle
Knob
Machine Screw
Wood Screw (long)
Wood Screw (short)
Wood Screw for Hinge
1 pc.
1 pc.
16 pcs.
16 pcs.
24 pcs.
20 pcs.
2 pcs.
2 pcs.
6 pcs.
8 pcs.
6 pcs.
27 pcs.
Tools recommended for assembly :Level
A2.
Top
1 pc.
Part List in carton 88 5033 942
Side Panel (B)
Side Panel (C)
Side Panel (D)
Side Panel (E)
Side Panel (F)
Side Panel (G)
Front Rail (H2)
Back Stretcher (I)
Back Panel (K)
Shelf (L)
Shelf (M)
Base (P)
1 pc.
1 pc.
1 pc.
1 pc.
1 pc.
1 pc.
2 pcs.
2 pcs.
2 pcs.
4 pcs.
1 pc.
1 pc.
Part List in carton 88 5033 942
Plinth (S)
Door (T)
Door (U)
2 pcs.
1 pc.
1 pc.
Patent 8,584,600 B2
