88 9100 002C

Kitchen Cart

IMPORTANT NOTE

Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the parts.

We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.

PART LIST

HARDWARE LIST

A.

Side Panel

1 pc.

B.
Side Panel
1 pc.

H.

Back Panel

3 pcs.

F.
Back Piece
2 pcs.

E2.
Front Piece
1 pc.

E1.

Front Piece

1 pc.

I.
Back Stretcher
1 pc.

J.
Front Stretcher
1 pc.

K.
Front Rail
3 pcs.

G.
Base
1 pc.

R.
Shelf
2 pcs.

L.

Side Rack

1 pc.

M.
Side Rack
1 pc.

O

Brush Chrome Pipes

3 pcs.

D.
Middle Panel
1 pc.

C.

Middle Panel

1 pc.

N.
Base Rack
1 pc.

(For Drawer U&V packed in separate carton
with hardware and assembly instructions.)

T.
Door
1 pc.

S.

Door

1 pc.

V.
KD. Drawer
1 pc.

U.
KD. Drawer
3 pcs.

P.
Handle Arm
2 pcs.

Q.
Round Arm
1 pc.

Tools Required For Assembly :

Phillips screwdriver

Home Styles Consumer Assistance Line 888-680-7460 and 877-831-0319

[email protected]

Hex Wrench
1 pc.

Machine Screw

for Knob

2 pcs.

Wood Screw
for Caster
16 pcs. (+2 extra)

Wood Plug
10 pcs.
(+2 extra)

Caster
two lock
two non-lock

4 pcs.

Adjustable Pin
8 pcs. (+2 extra)

Head Cap Bolt
14 pcs. (+1 extra)

Small
Hex Wrench
1 pc.

Knob
2 pcs.
