Page 7: Step 2 step 3 step 4, Step 1

Figure 2

MAKE SURE ROLLER
IS ON THE BACK

Figure 3

Figure 4

Insert

wood screws (4X)

into the pre-drilled holes in W5
and tighten. (see Figure 3)

short

Slide W5 into the grooves in W3
and W4. Be sure to push W5 all
the way forward so it meets W1.
(see Figure 2)

STEP 2

STEP 3

STEP 4

Tighten all screws used in drawer assembly.

Assemble Pull Handle with
machine screws. (see Figure 4)

Assembly Instructions 6/8

Part List

W1.
Front Part
1 pc.

W5.
Base Part
1 pc.

W2.
Back Part
1 pc.

W3.
Side Part
1 pc.

W4.
Side Part
1 pc.

Drawer (W)

Attach W1 to W3 and W4, using
a

and

wood screws

tighten halfway.

Attach W2 to W3 and W4 using

wood screws

tighten halfway. (see Figure 1)

Phillips screwdriver

(4X)

long

Figure 1

STEP 1
