How to:
Turn system on/off Press the On/Off” button once. Note: There
is a five (5) second time delay before the
system turns on or turns off.
Change Temperature Press the “Up” arrow once. The display will
show the existing temperature set point.
Press the up or down arrow buttons to adjust
the temperature to the desired set point.
Change Humidity Press the “Up Arrow” once. This display
will show the existing temperature set point.
Press the “Mode” button once to display the
Humidity setpoint.
Press the “Up” or “Down” arrows to adjust
the humidity to the desired set point. Note –
a Wine Guardian humidifier must be
installed and setting six (6) set to “1” or “2”
before the controller will let you change
percent humidity.
.
Change Mode --
Cooling/Heating/Auto Press the “Mode” button once to display the
“Set” function at the bottom of screen. The
existing mode will display next to the word
“Set” at the bottom of the screen.
Press the mode button again to scroll
through settings for “Cool” (cooling only),
“Heat” (heating only) or “Heat Cool”
(Auto).
STANDARD CONTROLLER FUNCTIONS
Humidity
Temperature
Alarm Indication
Area
Mode Area
Up Button
Down Button
Mode button (right side)
On/Off (left side)
