Radio configuration guide 80018044 Ver B 3
After the radio card is reset, it must have the following attributes:
• SSID: com.welchallyn
• Radio band: b/g
• Authentication type: WPA2-PSK
3. Ensure that the IP address is on the same subnet as the PC.
a. Touch the Network tab.
The IP address is displayed in the Radio window on the right.
Upgrading the radio software
You will need the following items to upgrade the radio software on your device:
• Welch Allyn Service Tool 1.5x or later.
• USB 2.0/5-pin type A to mini-B cable.
• A PC with Windows XP SP3 or Windows 7, Internet Explorer 7 or later, and
Internet access to connect to Welch Allyn PartnerConnect.
• Ethernet cable to connect the PC to the router.
• Wireless router 802.11 b/g
Connecting to the radio configuration tool web page
To connect to the radio configuration tool user interface
1. Use a USB cable to connect the device to a PC running the Welch Allyn Service tool.
2. Launch the service tool and log in.
Note Accessing the radio configuration tool requires your device radio to be reset to
factory defaults. If your device radio is not set to factory defaults, see
“Restore
the device radio settings to factory defaults.” on page 2.
Caution Only customer certificates and radio software should be changed using
the radio configuration tool user interface. All other configuration changes must
be completed through the device user interface. See the device directions for
use for more information.
Note Accessing the radio configuration tool requires your Welch Allyn device and your
PC running the Welch Allyn Service Tool to be connected to the same subnet.
Note You must log in with a BioMed user type in order to upgrade the radio software.
Router
PC
Device
USB
cable
Ethernet
cable
