Welch Allyn Connex ProBP 3400 Digital Blood Pressure Device - Quick Reference Guide User Manual

Page 7

background image

Error condition

Definition / Description

Required action

Device is operating in battery mode.

AC power cord has been
disconnected.

Click the OK button to dismiss the
message.

Plug the device into the outlet to
dismiss the message.

Powering down.

Device is performing normal
shutdown activities.

System error; disconnect patient
cables, power down, and restart.

System failure: fault is detected that
could adversely affect the product.

User must turn the VSM off using the
On/Off button.

Data did not transfer.

Data transfer unsuccessful with send. Click the OK button to dismiss the

message.

Data transfer successful.

Successful data transfer with
automatic or manual save

Click the OK button to dismiss the
message.

OpenTopic | ProBP3400 error codes | 7
