9
1 Install two fresh AA batteries in the recorder.
2 Plug the PC Interface Cable into a USB port
on your PC.
(a) Right-click on (My) Computer.
Before you start, install the CardioPerfect Workstation software.
INSTALLING THE ABPM 6100
ON A CARDIOPERFECT
WORKSTATION
The actual screens you see may appear slightly different
than what is pictured below.
(b) Select Properties.
If you have Windows XP, continue to step c.
If you have Windows 7 or Windows 8, go to step e.
(c) Click the Hardware tab.
(d) Click the Device Manager.
(e) Click the Device Manager.
(next page)
If the recorder is on, turn it off. ( Press and hold the Start/Stop
button for five seconds until the device emits five quick beeps.)
Start/Stop button
OR
Windows XP
Windows 7
and
Windows 8
e
d
c
b
