5
INSTALLING THE ECG RECORDER
ON A CARDIOPERFECT
WORKSTATION
Before you start, install the CardioPerfect Workstation software.
1 Assemble the ECG recorder, and then plug it into
any USB port.
2 Verify the installation of the ECG recorder.
Welch Allyn
CardioPerfect
(next page)
(a) Click Go.
(b) Select your test patient.
(c) Click ECG.
b
a
c
You will see square waves along with this message:
“Bad signal on Left Leg.”
Attach the patient cable to the recorder.
Attach clips to the ends of the lead wires.
Straighten a large metal paper clip.
Note Do not using a plastic-coated or painted paper clip.
