11
The recorder is ready to take a BP measurement.
You can give the recorder any name that you find helpful.
Press the Start/Stop button to turn the recorder on.
Press the Start/Stop button again to start the BP pump.
Press the Start/Stop button again to stop the BP pump.
When BP stops, verify that the recorder displays an error code
(“E” followed by a number).
Press and hold the Start/Stop button until you hear a series of
quick beeps (approximately 7 seconds) to turn the recorder off.
Attach the cable to the recorder.
Start/Stop button
The recorder turns on. (It turns on and off auto-
matically throughout this procedure.)
Disconnect the cable from the recorder.
(next page)
