CardioPerfect
PRO ECG Recorder - User Manual
DIR 80012763 Ver. F 12 / 26
1.1 Accessories
Your CardioPerfect Pro cardiograph allows the use of a broad range of accessories; contact
your local Welch Allyn Sales Office or your authorized Welch Allyn Dealer or Distributor.
NOTE All part numbers may not be available in all countries.
REF Component Description Purpose
CPR-UN-UB-D PC Based Resting ECG; non interpretive software
The Welch Allyn CardioPerfect
Pro Cardiograph is specifically
intended for the recording of
standard 12-lead electro-
cardiograms of patients. The
device is not suitable for direct
cardiac application.
CPR-UI-UB-D PC Based Resting ECG; interpretive software
CPRL-UN PC Based Resting ECG; Excludes patient cables
CPR-UN PC Based Resting ECG; Excludes patient cables
CPR-UN5 PC Based Resting ECG; Excludes patient cables;
5 meter USB cable
CPR-UN-EB PC Based Resting ECG
CPR-UN-EB-D PC Based Resting ECG; includes patient cables
and electrode set
CPR-UI-EB-D PC Based Resting ECG; Adult interpretive
software
CPR-UN-UB PC Based Resting ECG
CPR-UI-UB PC Based Resting ECG; Adult interpretive
software, USB cable
CPR-SN PC Based Resting ECG; Adult interpretive
software, Serial cable
RE-SW-MEANS CPWS software disk; with interpretation
Software upgrade from normal
resting algorithm to include
indicated data analysis options.
These options allow data
analysis by different methods.
Software enables user to view
and save electro-cardiograms of
patients on a PC. RE-SW-ECG CPWS software disk
RE-SW-PEDIA CPWS software disk; pediatric version with
interpretation
RE-SW-QT CPWS software disk; dispersion option
RE-SW-VCG CPWS software disk; vector option
RE-SW-RR CPWS software disk; interval option
RE-SW-HRV CPWS software disk; heart rate variability option
UPG-UN-UC-D-T CPWS software disk; upgrade from resting to
stress
Software upgrade from originally
purchased CPWS. Software
enables user to view and save
electro-cardiograms of patients
on a PC.
CCW-UPCPWR CPWS software disk; upgrade from DOS
Windows
UPDT-WACPW-CD CPWS software disk, update from older CPWS
versions
UPDT-WACPW-OW CPWS software disk; update from older versions,
out of warranty only
CPR-UPG-LTU CPWS software disk; upgrade from resting ―lite‖
resting ECG to normal ECG functionality
CPR-UPG-POR-1 CPWS software disk; upgrade from POR to
normal resting functionality
CPR-UPG-MD-1 CPWS software disk and cover, upgrade from
MDR to normal resting functionality
45008-0000 Alligator clips attachment (1k box) Clips allow user to connect
banana jack terminated patient
leads to electrode tabs needing
alligator clip attachment.
58581-0000 Alligator clips attachment (10 pack)
PRO-60023 PROLINK USB CABLE ASSEMBLY (2M)
Cable allows connection of the
Pro-Recorder to the PC USB
connector.
PRO-60024 PROLINK USB CABLE ASSEMBLY (3M)
PRO-60025 PROLINK USB CABLE ASSEMBLY (5M)
RE-PROLINK-SER SERIAL PRO RECORDER CABLE W/9P SUB D
CONN
Cable allows connection of the
Pro-Recorder to the PC serial
connector.
RE-LINK-SER UNILINK,RS232 FOR RESTING ECG
SE-PC-IEC-PUSH
Patient Cables;
PUSH style connector, ½ meter Cable allows connection of the
Pro-Recorder to the electrode
