System R-134a Charge Guidelines
System R-134a Charge Guidelines
Actual
Line
Length
System Charge (lbs) by Model #
(ft)
3000S
4000S
6000S
8000S
5
1.38
1.65
2.31
3.71
10
1.46
1.85
2.51
3.92
15
1.54
2.05
2.71
4.12
20
1.61
2.25
2.93
4.32
25
1.69
2.45
3.13
4.53
30
1.77
2.65
3.34
4.73
35
1.85
2.85
3.54
4.93
40
1.93
3.05
3.74
5.14
45
2.01
3.25
3.95
5.44
50
2.09
3.45
4.15
5.65
55
2.16
3.65
4.36
5.86
60
2.24
3.85
4.56
6.08
65
2.32
4.05
4.76
6.29
70
2.40
4.25
4.97
6.51
75
2.48
4.45
5.17
6.72
80
2.56
4.65
5.37
6.93
85
2.64
4.85
5.58
7.15
90
2.71
5.05
5.78
7.36
Note:
1) Actual charge may vary - follow charging instructions
detailed under Item 6 in the section titled Evacuation,
Leak Detection, and Charging
(above).
2) Lines sized according to Line Sizing Chart assuming act
line length plus 10 equivalent feet for fittings losses.
Ducting for the Evaporator
CellarPro Evaporators cold air exhaust and return can be ducted with a hood up
to 50 equivalent feet with 8” diameter ducting, or 100 equivalent feet with our
auxiliary fan and 8” diameter ducting. We offer a duct kit (sold separately) with
two fitting that attach to the front of the cooling unit and can be ducted.
We also offer a remote control panel kit that can be installed remotely (up to 10
feet) from the cooling unit, either inside or outside the cellar, and a bottle probe
(10 foot cord) that can be plugged into the cooling unit.
