14
Power Supply Requirements
EVAPORATOR CONDENSING UNIT
SPLIT
SYSTEM
FAN AMPS @ 115V/60HZ POWER INPUT WATTS
UNIT AMPS @
115V/60HZ
POWER
INPUT
MODEL MCA HIGH MED LOW HIGH MED LOW MCA LRA WATTS
3000S 1.3 1.0 0.8 0.7 107 84 70 6.4 28.2 442
4000S 1.7 1.4 1.1 1.0 159 122 107 9.2 40.0 591
6000S 2.6 2.1 1.7 1.4 214 168 140 13.5 53.0 922
8000S 3.5 2.8 2.2 1.9 318 244 214 15.4 51.0 1028
NOTES:
SPLIT
SYSTEM
SYSTEM AMPS POWER INPUT WATTS
MODEL MCA LRA HIGH MED LOW
3000S 7.4 28.0 549 526 512
4000S 10.6 40.0 750 713 698
6000S 15.6 53.0 1136 1090 1062
8000S 18.2 51.0 1346 1272 1242
NOTES:
Option A: Dual Power / Valve Control
Option B: Single Power / Electronic Control
1) A 15 amp dedicated circuit breaker (non GFI) is recommended for 3000S and 4000S systems.
2) A 25 amp dedicated circuit breaker (non GFI) is recommended for 6000S and 8000S systems.
1) Separate 115V / 60HZ power supplies are required for the Evaporator and the Condensing Unit.
2) A 15 amp circuit breaker is recommended for all Evaporator models.
3) A 15 amp dedicated circuit breaker (non GFI) is recommended for 3000S and 4000S Condensing
Units.
5) A 25 amp dedicated circuit breaker (non GFI) is recommended for the 8000S Condensing Unit.
4) A 20 amp dedicated circuit breaker (non GFI) is recommended for the 6000S Condensing Unit.
SINGLE 115V 60HZ POWER SUPPLY TO/FROM
EVAPORATOR
