MULTI SPEED FAN CONTROL
Designed for wine cellars up to 2000 cubic feet, the InCellar 8000 features multi-speed fans with a “high” setting
for maximum performance in high-temperature (+110°F) environments and a “low” setting for super-quiet
operation.
Fan Speed Selector Switch (Low/High): The cooling unit fans may operate on two speed settings: Low and
High. For optimum sound and energy efficiency, select the lowest fan speed that will maintain the desired cellar
temperature. If the relative humidity is low, a higher fan speed will cause less moisture to be removed during
cooling. High speed is recommended for initial cellar cool down.
Your fan speed selection will depend on the amount of heat that needs to be removed from the cellar and the
application of the unit. Fan speed selection will depend on the cellar size, insulation factor, door seal and desired
wine temperature. When initially installing the unit, set the fan speed to the Highest setting for a quick chill down.
Once the temperature of the cellar reaches the desired temperature, you may be able to select the lower fan speed to
handle the normal load. In the event the temperature of the intake air on the condenser side goes above 90 degrees,
you may need to select the higher fan speed.
Model 8000 8000
Speed Selection Low High
Air Flow
(CFM)
275 Evaporator Side 257 Condenser Side 303 Evaporator Side 279 Condenser Side
Sound
(dBA In Cellar / Out of Cellar)
65 Evaporator Side 54 Condenser Side 68 Evaporator Side 56 Condenser Side
Cooling Capacity
(BTU/h)
5610 6206
