InC 033114
Page 14 | 1-800-343-9463
From outside the cellar:
Make sure to remove all insulation or debris left inside either Plenum prior to sliding the cooling unit against the
cellar wall and connecting the Intake Plenum and the rear unattached Intake Plenum.
4. From outside the cellar seal all cracks and gaps where the two Intake Plenums meet on the inside of the
unattached Intake Plenum with an air-tight sealant or caulking to prevent heat transfer between the cellar and the
adjacent area (as shown in Figure 4).
5. Attach the Register to the unattached Intake Plenum.
6. Insert the Filter into the Register.
7. Plug in the Cooling Unit when finished ducting the exhaust on the condenser side of the unit.
Note: If you use decorative moulding, it should be attached to the walls and never to the cooling unit itself.
The moulding itself should be removable incase the unit needs servicing.
INSTALLING THE UNIT
FIGURE 4
