April 2012 Operations Manual CB901EX
GROUP CONFERENCE
Group Conference may be used for Emergency Communication/Paging.
Example:
10
AA916 Master station with Annunciator for display of Faults DAD104 ($09).
11-16 GS921DAM Handset Stations with Push ToTalk button.
17-20 IF935 Paging Interface.
Programming:
Master station 10.
SNA 10 1 09 (DAD assigned to master statation)
SPT 10 7 + (Activate Personal Que)
SPT 10 5 + (Activate Group Call Access)
Handset Stations 11-16.
SDT 11-16 7 (Direct Access Master)
SDA 11-16 10 (Faults are sent to 10)
SPT 11-16 10 + (Line Supervision)
SPT 11-16 5 + (Activate Group Call Access)
SDD 11-16 1 71 (Call Group Call 71 when handset is lifted)
Paging Interface 17-20.
SDT 17-20 1 (Sub)
SDA 17-20 10 (Faults are sent to 10)
SPT 17-20 10 + (Line Supervision)
Group Call 1 (71).
SGCM 10-20 1 + (Include stations 10 -20 in group call #1)
SGCP 1 2 + (T button must be used when talking)
SGCP 1 3 + (Activate Group Conference)
SST 10-20 4 30 (Set Group Call time limit to 30 seconds)
