Ring Communications CB901EX - Manual (Page 53)

April 2012 Operations Manual CB901EX
MDF Cable B9 DP980 MDF Cable B10
CARD HEX CALL PIN COLOR CARD HEX CALL
--------------------------------------------------------------------
33 B0
276 a 26 White-Blue 34 BC 288
b 1 Blue-White
+ 27 White-Orange
- 2 Orange-White
33 B1 277 a 28 White-Green 34 BD 289
b 3 Green-White
+ 29 White-Brown
- 4 Brown-White
33 B2 278 a 30 White-Slate 34 BE 290
b 5 Slate-White
+ 31 Red-Blue
- 6 Blue-Red
33 B3 279 a 32 Red-Orange 34 BF 291
b 7 Orange-Red
+ 33 Red-Green
- 8 Green-Red
33 B4 280 a 34 Red-Brown 35 C0 292
b 9 Brown-Red
+ 35 Red-Slate
- 10 Slate-Red
33 B5 281 a 36 Black-Blue 35 C1 293
b 11 Blue-Black
+ 37 Black-Orange
- 12 Orange-Black
33 B6 282 a 38 Black-Green 35 C2 294
b 13 Green-Black
+ 39 Black-Brown
- 14 Brown-Black
33 B7 283 a 40 Black-Slate 35 C3 295
b 15 Slate-Black
+ 41 Yellow-Blue
- 16 Blue-Yellow
34 B8 284 a 42 Yellow-Orange 35 C4 296
b 17 Orange-Yellow
+ 43 Yellow-Green
- 18 Green-Yellow
34 B9 285 a 44 Yellow-Brown 35 C5 297
b 19 Brown-Yellow
+ 45 Yellow-Slate
- 20 Slate-Yellow
34 BA 286 a 46 Violet-Blue 35 C6 298
b 21 Blue-Violet
+ 47 Violet-Orange
- 22 Orange-Violet
34 BB 287 a 48 Violet-Green 35 C7 299
b 23 Green-Violet
+ 49 Violet-Brown
- 24 Brown-Violet
--------------------------------------------------------------------
No Connection
50 Violet-Slate No Connection
No Connection 25 Slate-Violet No Connection
