April 2012 Operations Manual CB901EX
MDF Cable A11
DP979
MDF Cable A12
NFE1545 Interlink
FUNCTION
PIN
COLOR
FUNCTION
--------------------------------------------------------------------
LINK 8
RX 26
White-Blue
LINK 16
LINK 8
RX
1
Blue-White
LINK 16
LINK 8
TX
27
White-Orange
LINK 16
LINK 8
TX
2
Orange-White
LINK 16
LINK 7
RX 28
White-Green
LINK 15
LINK 7
RX
3
Green-White
LINK 15
LINK 7
TX
29
White-Brown
LINK 15
LINK 7
TX
4
Brown-White
LINK 15
LINK 6
RX 30
White-Slate
LINK 14
LINK 6
RX
5
Slate-White
LINK 14
LINK 6
TX 31
Red-Blue
LINK 14
LINK 6
TX
6
Blue-Red
LINK 14
LINK 5
RX 32
Red-Orange
LINK 13
LINK 5
RX 7
Orange-Red
LINK 13
LINK 5
TX 33
Red-Green
LINK 13
LINK 5
TX 8
Green-Red
LINK 13
34
Red-Brown
9
Brown-Red
35
Red-Slate
10
Slate-Red
LINK 4
RX 36
Black-Blue
LINK 12
LINK 4
RX 11
Blue-Black
LINK 12
LINK 4
TX 37
Black-Orange
LINK 12
LINK 4
TX 12
Orange-Black
LINK 12
LINK 3
RX 38
Black-Green
LINK 11
LINK 3
RX 13
Green-Black
LINK 11
LINK 3
TX 39
Black-Brown
LINK 11
LINK 3
TX 14
Brown-Black
LINK 11
LINK 2
RX 40
Black-Slate
LINK 10
LINK 2
RX 15
Slate-Black
LINK 10
LINK 2
TX 41
Yellow-Blue
LINK 10
LINK 2
TX 16
Blue-Yellow
LINK 10
LINK 1
RX 42
Yellow-Orange
LINK 9
LINK 1
RX 17
Orange-Yellow
LINK 9
LINK 1
TX 43
Yellow-Green
LINK 9
LINK 1
TX 18
Green-Yellow
LINK 9
44
Yellow-Brown
19
Brown-Yellow
45
Yellow-Slate
20
Slate-Yellow
--------------------------------------------------------------------
No Connection
46
Violet-Blue
No Connection
No Connection
21
Blue-Violet
No Connection
No Connection
47
Violet-Orange
No Connection
No Connection
22
Orange-Violet
No Connection
No Connection
48
Violet-Green
No Connection
No Connection
23
Green-Violet
No Connection
No Connection
49
Violet-Brown
No Connection
No Connection
24
Brown-Violet
No Connection
No Connection
50
Violet-Slate
No Connection
No Connection
25
Slate-Violet
No Connection
