Ring Communications CB901EX - Manual (Page 44)

CB901EX Operations Manual March 2011
MDF Cable A5 DP979 MDF Cable A6
CARD HEX CALL PIN COLOR CARD HEX CALL
--------------------------------------------------------------------
8 30 148 a 26 White-Blue 9 3C 160
b 1 Blue-White
+ 27 White-Orange
S 2 Orange-White
8 31 149 a 28 White-Green 9 3D 161
b 3 Green-White
+ 29 White-Brown
S 4 Brown-White
8 32 150 a 30 White-Slate 9 3E 162
b 5 Slate-White
+ 31 Red-Blue
S 6 Blue-Red
8 33 151 a 32 Red-Orange 9 3F 163
b 7 Orange-Red
+ 33 Red-Green
S 8 Green-Red
8 34 152 a 34 Red-Brown 10 40 164
b 9 Brown-Red
+ 35 Red-Slate
S
10 Slate-Red
8 35 153 a 36 Black-Blue 10 41 165
b 11 Blue-Black
+ 37 Black-Orange
S 12 Orange-Black
8 36 154 a 38 Black-Green 10 42 166
b 13 Green-Black
+ 39 Black-Brown
S
14 Brown-Black
8 37 155 a 40 Black-Slate 10 43 167
b 15 Slate-Black
+ 41 Yellow-Blue
S 16 Blue-Yellow
9 38 156 a 42 Yellow-Orange 10 44 168
b 17 Orange-Yellow
+ 43 Yellow-Green
S
18 Green-Yellow
9 39 157 a 44 Yellow-Brown 10 45 169
b 19 Brown-Yellow
+ 45 Yellow-Slate
S 20 Slate-Yellow
9 3A 158 a 46 Violet-Blue 10 46 170
b 21 Blue-Violet
+ 47 Violet-Orange
S
22 Orange-Violet
9 3B 159 a 48 Violet-Green 10 47 171
b 23 Green-Violet
+ 49 Violet-Brown
S 24 Brown-Violet
No Connection 50 Violet-Slate No Connection
No Connection 25 Slate-Violet No Connection
