CB901EX Operations Manual March 2011
EXTERNAL DEVICES DP979 MDF Cable A13
FUNCTION PIN COLOR
--------------------------------------------------------------------
Battery Ground 26 White-Blue PCB1019
Battery Ground 1 Blue-White PCB1019
27 White-Orange
2 Orange-White
28 White-Green
3 Green-White
29 White-Brown
4 Brown-White
30 White-Slate
5 Slate-White
31 Red-Blue
6 Blue-Red
32 Red-Orange
7 Orange-Red
RS485 DATA + 33 Red-Green PCB1019
RS485 DATA - 8 Green-Red PCB1019
34 Red-Brown
9 Brown-Red
35 Red-Slate
10 Slate-Red
36 Black-Blue
11 Blue-Black
37 Black-Orange
12 Orange-Black
38 Black-Green
13 Green-Black
39 Black-Brown
14 Brown-Black
40 Black-Slate
15 Slate-Black
41 Yellow-Blue
16 Blue-Yellow
42 Yellow-Orange
17 Orange-Yellow
43 Yellow-Green
18 Green-Yellow
44 Yellow-Brown
19 Brown-Yellow
45 Yellow-Slate
20 Slate-Yellow
No Connection 46 Violet-Blue
No Connection 21 Blue-Violet
No Connection 47 Violet-Orange
No Connection 22 Orange-Violet
No Connection 48 Violet-Green
No Connection 23 Green-Violet
No Connection 49 Violet-Brown
No Connection 24 Brown-Violet
No Connection 50 Violet-Slate
No Connection 25 Slate-Violet
