CB901EX Operations Manual March 2011
PROGRAM/ALARM DP979 MDF Cable A9
FUNCTION PIN COLOR
------------------------------------------------------
26 White-Blue
1 Blue-White
27 White-Orange
2 Orange-White
28 White-Green
3 Green-White
29 White-Brown
4 Brown-White
30 White-Slate
5 Slate-White
31 Red-Blue
6 Blue-Red
32 Red-Orange
7 Orange-Red
Battery Operation + 33 Red-Green
Battery Operation S 8 Green-Red
Alarm 2 Enable + 34 Red-Brown
Alarm 2 Enable S 9 Brown-Red
Alarm 1 Enable + 35 Red-Slate
Alarm 1 Enable S 10 Slate-Red
Program Channel 1 a 36 Black-Blue
Program Channel 1 b 11 Blue-Black
Program Channel 2 a 37 Black-Orange
Program Channel 2 b 12 Orange-Black
Program Channel 3 a 38 Black-Green
Program Channel 3 b 13 Green-Black
Program Channel 4 a 39 Black-Brown
Program Channel 4 b 14 Brown-Black
Program Channel 5 a 40 Black-Slate
Program Channel 5 b 15 Slate-Black
Program Channel 6 a 41 Yellow-Blue
Program Channel 6 b 16 Blue-Yellow
Program Channel 7 a 42 Yellow-Orange
Program Channel 7 b 17 Orange-Yellow
Program Channel 8 a 43 Yellow-Green
Program Channel 8 b 18 Green-Yellow
Alarm Channel 1 a 44 Yellow-Brown
Alarm Channel 1 b 19 Brown-Yellow
Alarm Channel 2 a 45 Yellow-Slate
Alarm Channel 2 b 20 Slate-Yellow
No Connection 46 Violet-Blue
No Connection 21 Blue-Violet
No Connection 47 Violet-Orange
No Connection 22 Orange-Violet
No Connection 48 Violet-Green
No Connection 23 Green-Violet
No Connection 49 Violet-Brown
No Connection 24 Brown-Violet
No Connection 50 Violet-Slate
No Connection 25 Slate-Violet
