April 2012 Operations Manual CB901EX
MDF Cable B1 DP980 MDF Cable B2
CARD HEX CALL PIN COLOR CARD HEX CALL
--------------------------------------------------------------------
21 50 180 a 26 White-Blue 22 5C 192
b 1 Blue-White
+ 27 White-Orange
- 2 Orange-White
21 51 181 a 28 White-Green 22 5D 193
b 3 Green-White
+ 29 White-Brown
- 4 Brown-White
21 52 182 a 30 White-Slate 22 5E 194
b 5 Slate-White
+ 31 Red-Blue
-- 6 Blue-Red
21 53 183 a 32 Red-Orange 22 5F 195
b 7 Orange-Red
+ 33 Red-Green
- 8 Green-Red
21 54 184 a 34 Red-Brown 23 60 196
b 9 Brown-Red
+ 35 Red-Slate
- 10 Slate-Red
21 55 185 a 36 Black-Blue 23 61 197
b 11 Blue-Black
+ 37 Black-Orange
- 12 Orange-Black
21 56 186 a 38 Black-Green 23 62 198
b 13 Green-Black
+ 39 Black-Brown
- 14 Brown-Black
21 57 187 a 40 Black-Slate 23 63 199
b 15 Slate-Black
+ 41 Yellow-Blue
- 16 Blue-Yellow
22 58 188 a 42 Yellow-Orange 23 64 200
b 17 Orange-Yellow
+ 43 Yellow-Green
- 18 Green-Yellow
22 59 189 a 44 Yellow-Brown 23 65 201
b 19 Brown-Yellow
+ 45 Yellow-Slate
- 20 Slate-Yellow
22 5A 190 a 46 Violet-Blue 23 66 202
b 21 Blue-Violet
+ 47 Violet-Orange
- 22 Orange-Violet
22 5B 191 a 48 Violet-Green 23 67 203
b 23 Green-Violet
+ 49 Violet-Brown
- 24 Brown-Violet
--------------------------------------------------------------------
No Connection 50 Violet-Slate No Connection
No Connection 25 Slate-Violet No Connection
