April 2012 Operations Manual CB901EX
MDF Cable A7 DP979 MDF Cable A8
CARD HEX CALL PIN COLOR CARD HEX CALL
--------------------------------------------------------------------
11 48 172 a 26 White-Blue 12 54 184
b 1 Blue-White
+ 27 White-Orange
S 2 Orange-White
11 49 173 a 28 White-Green 12 55 185
b 3 Green-White
+ 29 White-Brown
S 4 Brown-White
11 4A 174 a 30 White-Slate 12 56 186
b 5 Slate-White
+ 31 Red-Blue
S 6 Blue-Red
11 4B 175 a 32 Red-Orange 12 57 187
b 7 Orange-Red
+ 33 Red-Green
S 8 Green-Red
11 4C 176 a 34 Red-Brown 13 58 188
b 9 Brown-Red
+ 35 Red-Slate
S 10 Slate-Red
11 4D 177 a 36 Black-Blue 13 59 189
b 11 Blue-Black
+ 37 Black-Orange
S 12 Orange-Black
11 4E 178 a 38 Black-Green 13 5A 190
b 13 Green-Black
+ 39 Black-Brown
S 14 Brown-Black
11 4F 179 a 40 Black-Slate 13 5B 191
b 15 Slate-Black
+ 41 Yellow-Blue
S 16 Blue-Yellow
12 50 180 a 42 Yellow-Orange 13 5C 192
b 17 Orange-Yellow
+ 43 Yellow-Green
S 18 Green-Yellow
12 51 181 a 44 Yellow-Brown 13 5D 193
b 19 Brown-Yellow
+ 45 Yellow-Slate
S 20 Slate-Yellow
12 52 182 a 46 Violet-Blue 13 5E 194
b 21 Blue-Violet
+ 47 Violet-Orange
S 22 Orange-Violet
12 53 183 a 48 Violet-Green 13 5F 195
b 23 Green-Violet
+ 49 Violet-Brown
S 24 Brown-Violet
No Connection 50 Violet-Slate No Connection
No Connection 25 Slate-Violet No Connection
