CB901EX Operations Manual March 2011
MDF Cable B7 DP980 MDF Cable B8
CARD HEX CALL PIN COLOR CARD HEX CALL
--------------------------------------------------------------------
30 98
252 a 26 White-Blue 31 A4 264
b 1 Blue-White
+ 27 White-Orange
- 2 Orange-White
30 99 253 a 28 White-Green 31 A5 265
b 3 Green-White
+ 29 White-Brown
- 4 Brown-White
30 9A 254 a 30 White-Slate 31 A6 266
b 5 Slate-White
+ 31 Red-Blue
- 6 Blue-Red
30 9B 255 a 32 Red-Orange 31 A7 267
b 7 Orange-Red
+ 33 Red-Green
- 8 Green-Red
30 9C 256 a 34 Red-Brown 32 A8 268
b 9 Brown-Red
+ 35 Red-Slate
- 10 Slate-Red
30 9D 257 a 36 Black-Blue 32 A9 269
b 11 Blue-Black
+ 37 Black-Orange
- 12 Orange-Black
30 9E 258 a 38 Black-Green 32 AA 270
b 13 Green-Black
+ 39 Black-Brown
- 14 Brown-Black
30 9F 259 a 40 Black-Slate 32 AB 271
b 15 Slate-Black
+ 41 Yellow-Blue
- 16 Blue-Yellow
31 A0 260 a 42 Yellow-Orange 32 AC 272
b 17 Orange-Yellow
+ 43 Yellow-Green
- 18 Green-Yellow
31 A1 261 a 44 Yellow-Brown 32 AD 273
b 19 Brown-Yellow
+ 45 Yellow-Slate
- 20 Slate-Yellow
31 A2 262 a 46 Violet-Blue 32 AE 274
b 21 Blue-Violet
+ 47 Violet-Orange
- 22 Orange-Violet
31 A3 263 a 48 Violet-Green 32 AF 275
b 23 Green-Violet
+ 49 Violet-Brown
- 24 Brown-Violet
--------------------------------------------------------------------
No Connection 50 Violet-Slate No Connection
No Connection 25 Slate-Violet No Connection
Page 52 of 77
