Introduction 3
1.2.3 Lifting and Handling
Deck modules can be lifted (see Figure 1-2) using four chains or cables attached to the four gussets mounted on the
outside of the main beams. The gussets provide balanced lifting of the modules with bulkheads attached.
Figure 1-2. Unloading Modules From Truck
DANGER
Loads may disengage from crane scale hook and shackle or lifting eye if proper procedures are not
followed. A falling load may cause serious injury or death.
Never lift more than the crane scale’s assigned Working Load Limit (WLL) rating.
1.3 Serial Tag
The serial tag on an ATV Series portable truck scale truck scale is found at the end of the scale near the
SURVIVOR logo (see Figure 1-3). A duplicate tag is placed inside of the J-box pocket (see Figure 1-4).
Figure 1-3. Figure 1-4.
Figure 1-5. Serial Tag Placement (Module)
