Mounting Kits PR 6002 Installation Manual
EN-10 Sartorius
3.2 Technical Data
Mounting kit PR 6002/02S PR 6002/03S
Max. capacity of the load cell 1…10 t 25…50 t
Material Stainless steal Stainless steal
Weight, net 4.3 kg 4.6 kg
Mounting kit PR 6002/04S PR 6002/05S
Max. capacity of the load cell 1…10 t 25…50 t
Horizontal destructive force >35 kN >35 kN
Permissible lifting force 25 kN 25 kN
Destructive lifting force >40 kN >40 kN
Max. supporting capacity without load cell 25 kN 25 kN
Max. supporting capacity after delivery
(with transport bushing)
--- 100 kN
Destructive supporting capacity >100 kN >100 kN
Load cell clearance ±5 mm ±5 mm
Material Stainless steel Stainless steel
Weight, net 17 kg 17 kg
Mounting kit PR 6002/10S PR 6002/11S
Max. capacity of the load cell 1…10 t 25…50 t
Permissible lifting force 25 kN 25 kN
Destructive lifting force >40 kN >40 kN
Max. supporting capacity without load cell 25 kN 25 kN
Max. supporting capacity after delivery
(with transport bushing)
--- 100 kN
Destructive supporting capacity >100 kN >100 kN
Permissible horizontal force in constrainer direction 25 kN 25 kN
Horizontal destructive force in constrainer direction >50 kN >50 kN
Load cell clearance ±5 mm ±5 mm
Material Stainless steel Stainless steel
Weight, net 22.5 kg 22.5 kg
Mounting kit PR 6002/20S PR 6002/21S
Max. capacity of the load cell 1…10 t 25…50 t
Permissible lifting force 25 kN 25 kN
Destructive lifting force >80 kN >80 kN
Max. supporting capacity without load cell 25 kN 25 kN
Max. supporting capacity after delivery
(with transport bushing) --- 100 kN
Destructive supporting capacity >100 kN >100 kN
Permissible horizontal force in constrainer direction 50 kN 50 kN
Horizontal destructive force in constrainer direction >100 kN >100 kN
Load cell clearance ±5 mm ±5 mm
Material Stainless steel Stainless steel
Weight, net 34.5 kg 34.5 kg
