4.0 Configuration and Calibration
4.1 User and Setup Menu
The menu structure has two levels of security: an open user menu for driver operators and a password setup menu
for calibrations and options for making changes to the user menu.
Note
Options Alarms
Alarm 1
Alarm 2
Cells
CAN
Diagnostics
Menu
OLED
Info
Display
Split
Input 2
Input 1
Configuration
Span
Zero
Tare
Calibration
Modes
RS-232
PRINTER
Count
1 lb
10 lb
20 lb
50 lb
100 lb
200 lb
INC
ON
OFF
System
PUK
Pin
Clock
Net
Gross
Net & Gross
ON
OFF
Chan
Load
Z/Func
Keyboard
Inhibit
Keyboard
Printer
Printer CSV Data
Printer G PVWS
None
Format 1-4
Scoreboard
Net 4
Gross 4-5
G PVWS
BA4840
The default password is 0350. Keep this for your records.
Figure 4-1. User and Setup Menu – Electrical Wiring and Data Connections
User and Setup Menu
Parameter Choices Description
Display OLED
Info Adjust the brightness of the display; High, Med or Low.
Firmware version and serial number display.
Diagnostics Cells
CAN To display mV/V for load cells or transducers on separate channels.
To display CANbus diagnostics (not used).
Alarms Alarm 1
Alarm 2 Allows configuration of audible alarms.
Table 4-1. User and Setup Menu – Electrical Wiring and Data Connections
