CS200, Users
August, 2009
12
scale, but will also use the battery life more quickly. Press Zero until the desired
read rate is displayed. (see cal menu table above) Enter the read rate (1 to 7).
Press ZERO and BACKLIGHT together and release to enter the number
6. The scale shows “azt
azt
azt
azt”. Press ZERO and BACKLIGHT together and release.
Enter (0) to turn the auto-zero tracking off, enter (1) to turn it on. When on, small
loads (+/- 3 divisions) will automatically be zeroed off after a few seconds. Press
ZERO and BACKLIGHT together and release to enter the number. Default = 1.
7. The scale shows “dELY
dELY
dELY
dELY”. Press ZERO and BACKLIGHT together and release.
Enter (1) to turn the calibration delay on. If the delay is on: when the user
presses the keys to read a load point, there will be a 7 second delay until the
load point is actually read.
8. The scale shows “GrAd
GrAd
GrAd
GrAd”. Press ZERO and BACKLIGHT together and release.
The scale shows the current graduation selection. Use the following table to
select a graduation value. Press ZERO and BACKLIGHT together and release to
enter the number.
Setting Count by in lb Count by in kg
4
5
2
5
2
1
6
1
0.50
7
0.50
0.20
8
0.20
0.10
9
0.10
0.05
10
0.05
0.02
11
0.02
0.01
12
0.01
0.01
NOTE: The stated accuracy specifications are based on the graduation setting in
the table below. If the graduation setting is set other than the value in the table
below the accuracy specification remains with the graduation size listed below.
If your capacity is:
Set your graduation to:
25 lb / 12.5 kg
.01 lb / .01 kg (12)
50 lb / 25 kg
.02 lb / .01 kg (11)
100 lb / 50 kg
.05 lb / .02 kg (10)
250 lb / 125 kg
.1 lb / 0.05 kg (9)
500 lb / 250 kg
0.2 lb / 0.1 kg (8)
9. The scale shows “CAP
CAP
CAP
CAP”. Press ZERO and BACKLIGHT together and release.
Enter the scale's capacity in pounds.
At this point the gauge saves any changes that have been made
