CS200, Users
August, 2009
11
How to calibrate the CS200
The following details the calibration procedure for the Intercomp CS200 crane scale.
There are four parameters that can be set before entering the actual calibration. When
changing a value, advance at least to “save
save save save” before turning off so that your changes are
saved.
Step Description Note Recommended
rd rt rd rt rd rt rd rt Read rate 1 = 1 reads/sec
2 = 2 reads/sec
3 = 4 reads/sec
4 = 7 reads/sec
5 = 10 reads/sec
6 = 18 reads/sec
7 = 25 reads/sec 4
AZT AZT AZT AZT Auto Zero Tracking 0 = disabled, 1,2,3 3
dely dely dely dely calibration delay 0 = no delay
1 = 7 second delay for cal
points 1
grad grad grad grad graduation 4 = 5 lb
5 = 2 lb
6 = 1 lb
7 = 0.5 lb
8 = 0.2 lb
9 = 0.1 lb
10 = 0.05 lb
11 = 0.02 lb
12 = 0.01 lb
cap cap cap cap capacity
save
cal cal cal cal calibration type 1 =1 point cal linear
0101 = 3 point cal 0101
LL00 LL00 LL00 LL00 Zero read
LL01 LL01 LL01 LL01 Cal load 1 Enter load 1
LL02 LL02 LL02 LL02 Cal load 2 Enter load 2
LL03 LL03 LL03 LL03 Cal load 3 Enter load 3
Start up.
1. Turn the power OFF.
2. Remove the calibration blocking shunt to allow entry into calibration mode.
3. Turn the power ON.
4. Wait for scale to warm up (3 minutes from power on).
5. Press ZERO and BACKLIGHT together and release to enter the calibration
mode.
The scale shows “rd rt
rd rt rd rt rd rt”нннн. The read rate is the number of internal reads per
second the scale performs. A higher setting will result in a faster responding
