Introduction
5
1.0
Introduction
The EL232 XPCD is a high performance serial remote data display. It receives serial ASCII data (20 mA current
loop or RS-232), and displays weight data on a 8" LED display. Five LED status indicators are provided for Lbs,
Kg, Gross, Net, and no signal. (see Figure 1-1 on page 6).
The EL232 XPCD supports twelve scale formats which include:
•
UMC Series
•
General Freedom I and II
•
Electroscale 560
•
A & D Instruments 4322, 4323, 4316
•
Weightronix WI-110 and WI-120
•
Toledo indicators with “High speed data format”
•
Flex-weigh DWM-4
•
Analogic AN5315, AN5316, AN5322
•
Masstron M-2500 and M-5000
•
Fairbanks 90-164 series
•
Streeter Richardson 9000
•
Cardinal 738
•
Instruments with programmable ASCII output
•
Generic smart receiver mode
1.1
System Limitations and Restrictions
The following items represent limitations and restrictions on the use of the EL232 XPCD:
•
All wiring, connections, conduit and grounds must comply with the National Electrical Code.
•
No modifications can be made in the field.
•
It is mandatory to return the EL232 XPCD to Rice Lake Weighing Systems for service.
