14 RoughDeck HE AutoLift
4.4 Troubleshooting Guide
Symptom Probable Cause Solution
System does not
operate--no display Power disconnected Check and reconnect
Indicator fuse blown Replace fuse, check for cause
Interface cable cut or disconnected Repair
Signal leads incorrectly installed at indicator Install according to indicator installation manual
Display stays at zero Faulty load cell connections Check cable connections in J-box at indicator
Faulty indicator Service the indicator
Erratic weights Vibration near scale Remove source of vibration or move scale
Platform not level to within 1/4” Level the platform by adjusting feet or shimming
Load cell or cable water damage Replace load cell or cable
Debris under load cells or platform Clean
Indicator faulty Use simulator to test indicator stability; service
indicator
Consistently high or low
weights Indicator not properly adjusted to zero Zero the indicator according to operator’s manual
Platform binding Adjust clearance for free platform movement
Indicator not calibrated Calibrate according to indicator’s manual and
Section 3.3 on page 10
Faulty load cells Test and, if necessary, replace load cells
Feet touching deck’s underside Adjust feet downward to provide clearance
Table 4-2: Troubleshooting Guide.
