2 System 101 Basic Filler
1.3 Standard Features
The System 101 comes with the following standard features:
• Wallmount stainless steel enclosure
• Front panel switches including E-Stop, Reset/Resume, Start
• Softkeys for presets, CN#, Alpha-numeric ID#1, Alpha-numeric ID#2, and Totals
• Accumulating subtotal and total registers
• Transmitted audit trail
• Digital I/O board
• Relay rack and SSR relay outputs
• Fast feed
• Slow feed
• Fill complete (optional)
• Zero tolerance (optional)
The iRite program and source code that make up the 920i Flexweigh 101 Basic Filler are property of the
manufacturer. Modifications to this program and equipment must be performed by Rice Lake Weighing
Systems.
For more information on the iRite compiler utility program, refer to the 920i Installation and Operation Manual (PN 67887)
and is included with this product.
1.4 Button Functions
The functions of the front panel buttons for the System 101 are listed in Table 1-1.
1.5 Operation Menu Softkeys
Operation menu softkeys are defined to provide flexibility of operator functions for specific applications. Softkey
assignments are listed on the tabs shown at the bottom of the LCD display and softkey functions are activated by
pressing the arrow keys below the softkey tabs (Figure 1-1). They are password protected and offer access to the
following:
• Presets
• ID 1
• ID 2
• Totals
• Setup Menu
Front Panel Button Function
E-Stop Stops the filling process and removes power from the relays. It also puts the process into a paused state.
Start Starts the filling process.
Reset Aborts the fill process. This requires that the E-Stop button is in a stopped position.
Resume Starts the fill process from a paused state. This requires that the E-Stop is in a run position.
Table 1-1. Front Panel Button Functions
Important
