Filling a Container
Use the following steps to fill a container on the scale.
1. Place a container on the scale
2. Press the
Start
button on the unit. The system verifies if:
• Gross weight is within the zero tolerance
• E-Stop is pulled out
• A valid target weight is entered
The system increments the Consecutive Number by 1 on the main display.
The system tares the scale if Auto Tare is enabled (shown in the setup menu).
Figure 4-11. Fill Screen Example
The system begins filling either of three speeds and displays a basic filling screen although this screen will change
depending up what kind of filling is being done.
• Single Speed Filling - The system turns on fast fill until the target weight-preact weight is satisfied.
• Parallel Speed Filling - Turns on the fast fill and slow fill until the dribble weight is satisfied. The system
then turns off the fast fill and leaves the slow fill on until the target weight-preact weight is satisfied.
• Dual Speed Filling - Turns on the fast fill until the dribble weight is satisfied. The system turns on the
slow fill until the target weight-preact weight is satisfied.
System does the following when the target is reached:
• Capture a stable net weight
• Displays
remove container
• Updates the sub total weight and number of fills
• Updates the total and number of fills
• Turns on the Fill Complete Output
Once the container is removed and the weight falls within the Zero Tolerance, the Fill Complete Output is turned
off, the Zero Tolerance output is turned on, and the system is ready for the next fill.
4.4
Pausing/Resume/Reset a Fill
1. Press the E-Stop button. System turns off all outputs and displays
System Paused
.
2. Press the Resume switch to resume where the current batch left off.
Press the Reset switch to return back to Step 1 to start over.
