WLAN Installation Instructions 11
WiPort Technical Data
Table 4. WiPort Technical Data
Category Description
CPU, Memory Lantronix DSTni-EX 186 CPU, 256 KB zero wait state on chip SRAM, 2048 KB flash, 16 KB Bott ROM
Network Standards IEEE 802.11b; IEEE 802.11g
Frequency Range 2.412 - 2.484 GHz
Antenna Connector 1, no diversity supported
Data Rates 1, 2, 5.5, 11 Mbps (802.11b)
6, 9, 12, 18, 24, 36, 48, 54 Mbps (802.11g)
Firmware Upgradeable via TFTP and serial port
Serial Line Formats 7 or 8 data bits, 1-2 stop bits, parity: odd, even, non
Modem Control DTR, DCD
Flow Control XON/XOFF (software), CTS/RTS (hardware), none
Network Interface Wireless 802.11b. 802.11g, and 10/100 Ethernet
Protocols Supported ARP, UDP, TCP, Telnet, ICMP, SNMP, DHCP, BOOTP, Auto IP, HTTP, SMTP, TFTP
Frequency Range 2.412-2.484 GHz
Range Up to 328 feet (100 m) line of sight
Maximum Receive Level -10 dBm (with PER < 8%)
Receiver Sensitivity -72 dBm for 54 Mbps
-87 dBm for 11 Mbps
-89 dBm for 5.5 Mbps
-90 dBm for 2.0 Mbps
-92 dBm for 1.0 Mbps
Modulation Techniques OFDM
DSSS
CCK
DQPSK
DBPSK
64 QAM
16 QAM
Number of Selectable Channels Up to 14 channels. Profiles available will include USA, France, Japan, Spain, Canada, and "other"
(multiple countries).
Modulations OFDM, DSSS, DBPSK, DQPSK, CCK, 16QAM, 64QAM
Transmit Output Power 14 dBm + 1.5 dBm/-1.0 dBm
Peak Supply Current at 3.3V 650 mA
Management Internal web server, SNMP (read only)
Serial login, Telnet login
DeviceInstaller software
Security Password protection, locking features, 64/128-bit WEP, WPA-PSK, End-to-End AES
Internal Web Server Serves web pages
Storage capacity: 1.2 MB
Temperature Operating range: -30º C to +70º C (-22º F - 158º F)
Storage range: 30º C to +70º C (-22º F - 158º F)
Included Software Windows-based DeviceInstaller configuration software and Windows-based Comm Port Redirector,
DeviceInstaller, Web Manager
Lantronix web site: http://www.lantronix.com
