ProgressiveRC 308Duo iCharger - Manual (Page 15)

308DUO V1.6.0
Synchronous Balance Charger/Discharger
- 15 -
Press STATUS-x button for 2 seconds when running program to pop up MODIFY interface, to modify the current and
discharge voltage parameters online, as below:
Press STOP/START-x button when running program to stop running, and press STOP/START-x button again to return to
the initial interface.
 Error Messages
During the running program, if the system detects an error, it will stop running the program on the channel immediately
and pop up the red dialog box and the buzzer alarms, as below:
 Program Edit
After adding new programs or editing saved programs, the system will enter MEMORY SETUP interface. Users can set
or modify the program on this interface.
Note: 1. When editing the program name, the character can be selected by turning the Knob, and
clicking the Knob to confirm the selected character. Clicking TAB/SYS button will delete the
character. Double-click Knob after editing program name. If the program name is empty, the
system will name it automatically.
2. If the Editing program is the built-in program, the program name and battery type etc.
parameters cannot be changed.
After setting the basic parameters of a battery, click " " to enter MEMORY OPTION interface, after setting click
“ ” to return to MEMORY SETUP, and click “ ” to save.
1: Error number
2: Error message
See all details on Page41 Error Messages.
1: Program name 2: Battery type
3: Number of cells 4: Battery capacity
5: Available program
2
1
5
2
3
4
1
