Mercedes-Benz R-Class 2010 Owners Manual - Manual (Page 348)

Vehicle specification R 350 BlueTEC
(251.125)
The quoted data apply only to the standard
vehicle. Contact an authorized Mercedes-
Benz Center for the corresponding data of all
special bodies and special equipment.
Engine R 350 BlueTEC
Engine, type 642
Mode of operation Diesel 4-stroke
engine
No. of cylinders 6
Bore 3.27 in (83.00 mm)
Stroke 3.62 in (92.00 mm)
Total piston
displacement
182.3 cu in
(2 987 cm 3 )
Compression
ratio
16.5:1
Output acc. to
SAE J 1349
210 hp/3 400 rpm
(157 kW/3 400 rpm)
Maximum torque
acc. to SAE J 1349
400 lb-ft/
1 600 - 2 400 rpm
(543 Nm/
1 600 - 2 400 rpm)
Maximum engine
speed
4 500 rpm
Firing order 1-4-2-5-3-6
Poly-V-belt 2 035 mm
Electrical system R 350 BlueTEC
Alternator 14 V/220 A
Starter motor 12 V/2.0 kW
Battery 12 V/95 Ah
Main dimensions R 350 BlueTEC
Overall vehicle
length
203.7 in (5 173 mm)
Overall vehicle
width
20
85.4 in (2 168 mm)
Overall vehicle
height
21
65.5 in (1 663 mm)
Wheelbase 126.6 in (3 215 mm)
Track, front 64.7 in (1 643 mm)
Track, rear 64.4 in (1 636 mm)
Ground
clearance
21
5.8 in (148 mm)
Turning circle 40.7 ft (12.4 m)
Weights R 350 BlueTEC
Roof load max. 220 lb (100 kg)
Vehicle specification R 350 (251.165)
The quoted data apply only to the standard
vehicle. Contact an authorized Mercedes-
Benz Center for the corresponding data of all
special bodies and special equipment.
Engine R 350
Engine, type 272
Mode of operation 4-stroke engine,
gasoline injection
No. of cylinders 6
Bore 3.66 in (92.90 mm)
Stroke 3.39 in (86.00 mm)
Total piston
displacement
213.5 cu in
(3 498 cm 3 )
20 Exterior rear view mirrors folded out.
21 Data apply to unladen vehicle with standard equipment. Data may vary in vehicles equipped with AIRMATIC
depending on the selected damping settings and the current vehicle level.
