ii
RADIO/ELECTRICAL
A suggested radio layout is provided in this manual. Your high performance R/C center should be consulted regarding
specifics on radio/electrical equipment. However, we recommend using a steering servo with a minimum of 50 oz-in of
torque.
HARDWARE IDENTIFICATION
When in question, use the hardware identification guide in each step. For screws, the prefix number designates the
screw size and number of threads per inch (i.e., 4-40 is #4 screw with 40 threads per inch of length). The fraction
following designates the length of the threads for cap head screws, and the overall length for flathead screws. Bearings
and bushings are referenced by the inside diameter x outside diameter. Shafts and pins are diameter x length. Washers
are described by inside diameter or the screw size that will pass through the inside diameter. E-clips are sized by the shaft
diameter that they are attached to.
FUEL
The fuel used to power the XXX-NT Sport truck is a special blend of methanol, oils, and nitromethane. This fuel is highly
flammable and should be treated with extreme caution. Be sure to read any warnings and cautions that appear on the
packaging of the fuel. Because exhaust fumes are produced from running fuel powered models, this model should not be
operated indoors. Be careful when handling your truck while the motor is running. Avoid pointing the exhaust outlet
towards your face. The exhaust fumes can cause irritation and burning of the eyes.
There are a number of different brands of model fuels available. We have found that fuels specially blended for R/C car
use like Blue Thunder, Trinity, and Orion perform better than common model airplane or helicopter fuels. Model airplane
fuels usually do not have the proper type or amount of oil needed for the extreme demands of R/C car racing.
FUEL BOTTLE
You will need some sort of a fuel bottle in order to fill the tank in your XXX-NT Sport with fuel. Your local hobby shop
should have fuel bottles available.
STARTERS
If you will be installing an engine that is not equipped with a pull-start, you will need to have some sort of an electric starter
in order to start the engine. There are several hand-held electric starters available on the market. There are also a few
manufacturers that produce starter boxes. A starter box is easier to use, but is usually more expensive. When attempting
to start the engine in your truck with an electric starter, make certain that the engine is being turned the correct direction
(counter-clockwise). Turning the engine over the wrong direction will cause the engine to not start or possibly run back-
wards.
GLOW IGNITER
You will also need a glow plug igniter in order to start the engine in your XXX-NT Sport. There is a wide variety of glow plug
igniters available. Check with your local hobby shop.
Team Losi is continually changing and improving designs; therefore, the actual part may appear slightly different than the illustrated part. Illustrations of
parts and assemblies may be slightly distorted to enhance pertinent details.
TABLE OF CONTENTS
1. INTRODUCTION ..................................................................... i
Completed Kit Dimensions ................................................ i
Notes & Symbols ................................................................ i
Kit Manual Organization ..................................................... i
Important Safety Notes ....................................................... i
Tools Required ..................................................................... i
Radio/Electrical .................................................................. ii
Hardware Identification ...................................................... ii
Fuel ...................................................................................... ii
Fuel Bottle ........................................................................... ii
Starters ................................................................................ ii
Glow Igniter ......................................................................... ii
2. BAG A ................................................................................. 1-6
3. BAG B ............................................................................... 7-11
4. BAG C ............................................................................ 12-21
5. BAG D ............................................................................ 22-26
6. BAG E ............................................................................ 27-30
7. BAG F .................................................................................. 31
8. Engine Installation ........................................................ 32-39
9. Radio Installation .......................................................... 40-51
10. Final Assembly ................................................................... 52
11. Final Checklist .................................................................... 53
12. Tips from the Team ....................................................... 53-55
13. Spare parts .................................................................... 56-59
