9 AM4204
www.kontron.com
2.4 SFP Front IO
The four front SFP cage support multi-rate copper and fiber SFP modules. The ports are numbered on the
front panel overlay
Table 2-1: SFP Connections
SFP modules are not provided with the AM4204 and have to be obtained separately. The SFP uplink ports are
compliant to the Small Form-factor Pluggable (SFP) Transceiver MultiSource Agreement (MSA), Sept. 14th
2000. An application note with a list of SFP modules successfully operated by Kontron in the AM4204 is
available upon request.
Each SFP port has green LED with the following signification:
Table 2-2: SFP LED Significations
2.5 Dual Gigabit Ethernet Controller
A dual Gigabit Ethernet controller is connected to PCIe port 2 of the Octeon Processor. The two GbE lines are
connected to ports 0 and 1 of the AMC connector.
SFP Connection Octeon Block
1 GbE eth 6 PKO/IPD port 16, QLM3 GMX1 index 0
2 GbE eth 7 PKO/IPD port 17, QLM3 GMX1 index 1
3 GbE eth 8 PKO/IPD port 18, QLM3 GMX1 index 2
4 GbE eth 9 PKO/IPD port 19, QLM3 GMX1 index 3
CAUTION LASER LIGHT!
Do not look into the laser beam!
The SFP modules are fitted with a class 1 or 1M laser. To avoid possible exposure to
hazardous levels of invisible laser radiation, do not exceed maximum ratings.
LED Signification
Green on Link 1Gbit
Green blink Activity 1Gbit
Signal Path:
The two GbE lines are connected to ports 0 and 1 of the AMC connector.
