23 AM4210
www.kontron.com
/sbin/rc starting
Updating module dependencies
Loading IPv6 module
Mounting file systems
Setting up loopback
Starting syslogd
Jan 1 00:00:06 (none) syslog.info syslogd started: BusyBox v1.2.1
Starting telnetd
Mounting /dev/mtd4 to /mnt
Execute /mnt/etc/rc.local
cavium-ethernet: Cavium Networks Octeon SDK version 1.8.1, build 244
Interface 0 has 4 ports (SGMII)
Interface 1 has 4 ports (SGMII)
Interface 3 has 4 ports (LOOP)
Configure eth6 / SFP0 for IP 192.168.0.100/24
Start DHCP client on eth0 / AMC Port 0
udhcpc (v1.2.1) started
[...]
adding dns 192.168.50.2
/sbin/rc Jan 1 00:00:09 (none) daemon.info init: Starting pid 904, console /dev/ttyS0: '/
bin/sh'
BusyBox v1.2.1 (2008.06.05-14:58+0000) Built-in shell (ash)
Enter 'help' for a list of built-in commands.
~ #
The connection is terminated by pressing the escape character sequence “~.” (without quotes).
3.5 Using the cfgtool
A tool to configure the CPU settings will be provided. This tool shall configure the strapping options, apply
the changes to the MMC and update the E-keying information in the Multi-Record section of the FRU data.
The MMC is responsible for saving and restoring these settings.
• The cfgtool allows to configure the PCIe settings.
• The cfgtool allows to configure the QLM 1 and QLM 3 settings.
• The cfgtool allows to perform a validly check before setting the new configuration.
• The cfgtool allows to update the e-keying information related to the performed changes.
• The cfgtool allows to update the e-keying information to meat the “multi flavor” settings.
• The cfgtool allows to change the multirecord area when updating the e-keying information.
• The cfgtool allows to configure PCIe clock source
Note:
SoL over AMC port 0 (Intel 82571EB) will only work with AT8050, AT8030, AT8404, AT8402 and
AT890xM, using an AT8010 or AT8020 it will not work, since there is no GbE on Port 0 available.
