Standards Compliance
•
This board is compatible to the following standards:
•
AMC.0 R2.0 Advance Mezzanine Card Base Specification
•
AMC.1 R2.0 PCI Express and Advance Switching
•
AMC.1 Type 4
•
AMC.2 R2.0 Type 4 and Type 5
•
IPMI v1.5.
•
IEEE 802.3
•
The AM4210 is RoHS compliant.
Mechanical
Characteristics
•
4HP single Mid-size AMC Module
•
Board is compliant with AMC.0 R2.0
Operating Voltages
•
Management:
3.3V +/-0.3V
•
Payload:
10VDC to 14VDC
Operation Power
•
Management:
500mW max., 400mW typ.
•
Payload:
38.4W max., 29W typ.
Temperature
•
This board is designed for operation from 5°C to 70°C ambient air temperature with forced
convection.
•
Operating @ 10 CFM:
5°C to 45°C
•
Operating @ 15 CFM:
5°C to 65°C
•
Short term operating @ 25 CFM:
-5°C to 75°C
•
Non-Operating:
-40°C to 70°C
Humidity
•
The board is designed to meet Bellcore GR63, Section 4.1
•
Operating:
15%-90% (non-condensing) at 55°C
•
Non-Operating:
5%-95% (non-condensing) at 40°C
Altitude
•
The board is designed to meet the following requirements according to Belcore GR-63, section
4.1.3:
•
Operating:
4000 m (13123 ft) (GR63 4.1.3), may require
additional cooling above 1800m (5905ft)
•
Non-Operating:
15000 m (49212 ft)
Vibration
•
The board is designed to meet the following requirements according to EN 300 019, Telcore GR-
63 and IEC 60068:
•
Operating:
• 5 Hz to 200Hz 0.2G, 5mm/s (sinusoidal)
• 5 Hz to 100Hz: 0.1G @ 0.1 Octave/minute (sinusoidal)
• 5 Hz to 100Hz: 1G @0.1 Octave/minute (sinusoidal)
• 0,02 m²/s³ ASD, 5-10Hz +12dB/oct, 10-50Hz 0dB/oct, 50-100Hz -12dB/oct (random)
•
Non-Operating (packaged enclosure):
• 5 Hz to 200Hz 2G, 5mm/s (sinusoidal)
• 0,02 m²/s³ ASD, 5-10Hz +12dB/oct, 10-50Hz 0dB/oct, 50-100Hz -12dB/oct (random)
• 5 Hz to 20 Hz: 0.01g²/Hz (random)
• 20 Hz to 200 Hz: -3dB/octave (random)
