1.2 What’s Included
This board is shipped with the following items:
• One AM4210 AMC board
• One DB9 to RJ45 adaptor
• One Documentation & Drivers disk
If any item is missing or damaged, contact the supplier.
1.3 Board Specifications
Table 1-1: Board Specifications
Features Description
Multicore Processor Unit
• Cavium Octeon Plus CN5650-600 BG1217-NSP-G
• Socketless
Memory
• 2 or 4 Gigabyte DDR2 Memory support with ECC (2GB standard)
• 18 JEDEC standard 60ball FBGA (x8) DDR2 SRAM Devices
• 800MHz data rate
• Socketless
Flash Memory
• 128MB Flash Memory
• Boot sector protection
USB SSD Flash Module
• NAND flash memory.
• Single Port USB 2.0 interface
• Capacities: 4GB and 16GB
• Package: Low Profile Package
Dual Gigabit Ethernet
Controller
• Dual Gigabit Ethernet Controller Intel 82571EB
• PCIe x4 interface to processor
• 2 1000Base-BX (Serdes) interfaces to AMC connector
• Serial-over-LAN Support via SMB
IPMI
• IPMI 1.5 compliant
• Voltage and Temperature Sensors
• ATCA LED control
• FRU data storage for AMC
• Firmware Update handling for field upgrades, rollbacks and watchdog functions
I/O Interfaces
• Front: 1 SFP+ cage to support multi-rate fiber SFP+ modules
• Front: RJ45 for RS232 access to Processor
• AMC TCLKA support
• AMC FCLKA input with 100MHZ without SSC
• AMC Port 0 and Port 1: 1000Base-BX
• AMC Port 4 to Port 7: Configurable x4 PCIe Root Complex or target mode
• AMC port 8 to port 11 : Configurable 1x 10GbE or 4x GbE
• AMC Port 15: RS232 (proprietary mapping)
