2.4 SFP+ Front IO
The front SFP+ cage support multi-rate fiber SFP+ module.
Table 2-1: SFP+ Connection
SFP+ module is not provided with the AM4210 and have to be obtained separately. The SFP+ uplink port is
compliant to the Enhanced 8.5 and 10 Gigabit Small Form Factor Pluggable Module “SFP+” MultiSource
Agreement (MSA), February 16th 2007, and the Improved Pluggable Formfactor MSA, February 26th 2007.
An application note with a list of SFP+ modules successfully operated by Kontron in the AM4210 is available
upon request.
The SFP+ port has a bi-color green/amber LED with the following signification:
Table 2-2: SFP+ LED Significations
2.5 Dual Gigabit Ethernet Controller
A dual Gigabit Ethernet controller is connected to PCIe port 2 of the Octeon Processor. The two GbE lines are
connected to ports 0 and 1 of the AMC connector.
2.6 RS232 Management Interface
The RS232 interface of the Octeon is connected to the front panel RJ45 connector and to the AMC port 15
(RTM connection). If a terminal is connected to the front port, the RTM connection is disabled.
SFP+ Connection
1 10 GbE XAUI0
CAUTION LASER LIGHT!
Do not look into the laser beam!
The SFP+ module is fitted with a class 1 or 1M laser. To avoid possible exposure to
hazardous levels of invisible laser radiation, do not exceed maximum ratings.
LED Signification
Green on Link 10Gbit
Green blink Activity 10Gbit
Amber on Link 1000Mbit
Amber blink Activity 1000Mbit
Signal Path:
The two GbE lines are connected to ports 0 and 1 of the AMC connector.
