KTD-N0903-A
Page 16
Rear IO Connectors
mITX-E38 Users Guide
6
Rear IO Connectors
DC Power Jack Connector (Ext12V – J35)
6.1
Either the DC Power Jack Connector (Ext12V) or the “Int12V.” connector must be used to supply the board
with +12V +/-5%.
The Ext12V power connector has Vin to the center pin and mates with Ø 6.3 mm DC Power jack with Ø 2.0
mm pin hole. (DC Connector RA 2mm locking type). Maximum allowed current is 5A.
Warning: Hot Plugging power supply is not supported. Hot plugging might damage the board.
