VMP1 Configuration
ID 26037, Rev. 01 Page 4 - 19 ® 2002 PEP Modular Computers GmbH
4.3.7 EEPROM
Access to the EEPROM is effected via the I2C bus of the MPC8240. The EEPROM
uses the I2C address 0xA0.
For more detailed information please refer to the manuals for the MICROCHIP 24LC16B
and the MOTOROLA MPC8240 (I2C bus).
4.3.8 Digital Temperature Sensor
Access to the onboard temperature sensor is effected via the I2C bus of the MPC8240.
The EEPROM uses the I2C address 0x90.
For more detailed information please refer to the manuals for the National Semiconduc-
tor LM75 and the MOTOROLA MPC8240 (I2C bus).
