VMP1 VMP1-IO1 Module (Optional)
ID 26037, Rev. 01 Page A - 5 ® 2002 PEP Modular Computers GmbH
C Board Layout
The VMP1-IO1 has two onboard connectors (CON9 and CON10) which provide all the
PCI signals and the power supply for the PMC module.
Figure A-1: Board Layout (Front View)
1
100
99
2 PCI EXPANSION CONNECTOR
1 2
63 64
1 2
63 64
DC/DC
MAGNIFIED
