VMP1 Introduction
ID 26037, Rev. 01 Page 1 - 7 ® 2002 PEP Modular Computers GmbH
Debug Interface JTAG/BDM
VME Connector 96-pin VME connector
Onboard Connectors 2 x RJ45 for RS232, 1 x RJ45 for Ethernet
PCI Expansion Modules
PMC carrier, future PCI based I/O board with
VGA/SCSI/2
nd
Ethernet
Mechanical Conformance Conforms with IEEE 1101.10
Power Supply
5V in accordance with the VME Specification, 1.79 Amp
current
Temperature Range
–40°C to +85°C (operating)
–55°C to +125°C (storage)
Humidity 0% to 95% non-condensing
Dimensions 100mm x 160mm single-height Eurocard
Board Weight 182 grams
Table 1-1: VMP1 Main Specifications
VMP1 Specifications
