4.3 Board Address Map

4.3.1

Address Map Overview

Figure 4-1: VMP1 Address Map, 2 MB 8-bit Bank

DRAM

Configuration

Address

RESERVED

unusable

PCI / VME

BANK0

mirror Bank 0

Reset Entry

0xFFF0 0100

0xFFFF FFFF

0xFFE0 0000

0xFF80 0000

0xFF00 0000

0xFEC0 0000

0x0000 0000

0x4000 0000

0x8000 0000

0xFEC0 0000

PCI Interrupt Ack

Configuration DATA

0xFFE0 0000

0xFEF0 0000

0xFEE0 0000
